March 2005
Introduction
Bromine monoxide total column values are derived from GOME and SCIAMACHY spectra. This level-2 data is the bases of the BrO level-3 global fields. At a later stage, the tropospheric part of the total column will be derived.
Archives
The BrO Level-3 Product consists of:- Monthly Maps
- Composite 3-Days Maps
- Daily Maps
- Overpasses: times series over pre-defined stations known for carrying on BrO measurements
Example:
|
|
The montly maps of BrO from GOME (left) and SCIAMACHY (right) on the Southern hemisphere for the month of March 2003. |
Documentation and related subjects
- The level-3 product is based on GOME and SCIAMACHY BrO Level-2 Products.
- General introduction on Bromine monoxide in the atmosphere and the retrieval of BrO.
- BrO product validation
- Service Report Protocols (inc. format description)
